OLTC Type	CM	SHM-DL	CMA7
Rated voltage (V)	220 V/AC		380 V/AC
Rated frequency (Hz)	50 or 60
Rated power (W)	750		750	1100
Rated current (A)	6		2	2.9
Rated torque on drive shaft (Nm)	25		18	26
Revolution of the drive shaft per switching operation	33
Revolution of the hand crank per switching operation	33
Running time per switching operation (s)	Approx. 5
Max. operation positions	107
Voltage for control circuit and heater circuit (V)	220 V/AC
AC voltage test to ground (kV/50Hz, 1 min)	2
Approximate weight (kg)	80		110	90
Protective degree	IP66			IP56
